STRONG HD STB User’s Manual
REAR PANEL CONNECTOR SPECIFICATIONS
34
Audio Output Connector
Label Meaning Connector Comment
L – TV Left White RCA jack Audio Lo or Lt
R – TV Right Red RCA jack Audio Ro or Rt
L – LINE Left – fixed level White RCA jack Audio Lo or Lt
R – LINE Right – fixed level Red RCA jack Audio Ro or Rt
SPDIF Digital audio output TOS-LINK AC-3 stream / PCM
SPDIF Digital audio output Black RCA Jack AC-3 stream / PCM
Video Output 1 – RGB, YPbPr
Label Meaning Connector Comment
R/Pr Red/R-Y 15-p DB 0.7Vpp at 75 ohm
G/Y Green/Luminance 15-p DB 0.7Vpp at 75 ohm
B/Pb Blue/B-Y 15-p DB 0.7Vpp at 75 ohm
HD Horizontal sync 15-p DB 4 Vpp at 75 ohm
VD Vertical sync 15-p DB 4 Vpp at 75 ohm
Video Output 2 – Component
CAUTION : These signals are connected together with VGA
Label Meaning Connector Comment
Y Green RCA jack 1Vpp at 75 ohm
Pb Blue RCA jack 0.7Vpp at 75 ohm
Pr Red RCA jack 0.7Vpp at 75 ohm
Pin number Definition Pin number Definition Pin number Definition
1 R/Pr 6 GND 11 11 MS0
2 G/Y 7 GND 12 12 MS1
3 B/Pb 8 VS 13 13 HS
4 MS2 9 NC 14 14 VS
5 GND 10 GND 15 15 MS3
