STRONG HD STB User’s Manual
6
VGA OUT : RGB/VGA component output for connecting the STB to a television using a
VGA cable.
S-VIDEO : S-video jacks for connecting the STB to an S-Video compatible VCR or
television.
S/PDIF OPTICAL : Digital audio output for connecting the STB to your AV receiver or Dolby
Digital decoder using optical cable. Set this output to AC-3 Dolby Digital
or Stereo PCM in the STB setup menu or by the SAP button on the
remote control
RS-232C : RS232C serial connection for future upgrades of the STB.
DVI-I OUT : Digital video signal and RGB component output for connecting the STB to a
television using a DVI cable.
NOTE : The YPbPr, VGA and DVI-I outputs carry the same R/G/B signals using
different physical connectors. Choose only one – do not use both at the same
time.
AC POWER INLET : Inlet to connect the STB to a standard power wall outlet.
