HONEYCOMB AIR DIFFUSER
Honeycomb Air Diffuser
• Honeycomb is located in discharge air duct.
• See illustration below.
• Note: Illustration shown below is partially disassembled for illustrative purposes only.
Honeycomb Air
Diffuser
