INSTALLATION, CONTINUED: POSITIONING & ALIGNING CASE / ADJUSTING LEVELERS
3. Position & Align Alongside Other Cases
• Before adjusting levelers, make certain that the case is in proper position and, if required, aligned with
adjoining case(s).
• This may require the repositioning of the case you are installing or the already positioned cases.
4. Adjusting Levelers
• Important! After case is in proper position, levelers must then be LOWERED to floor.
• Adjust levelers so the case is level and plumb.
• You may need to remove front and/or rear toe-kick to access levelers.
• Use adjustable wrench to adjust leveler.
• Depending upon case weight it may be necessary to use a pry bar to accomplish this task.
• Do not use pry bar on toe-kick as it may buckle.
• Do not use pry bar on end panel as it may chip.
• Use pry bar ONLY on base frame to avoid damaging case.
• See illustrations below.
Pry Bar
Base Frame
Adjustable
Wrench
Leveler
