5
INSTALLATION: CASE REMOVAL (VIA LEVELERS & CASTERS)
1. Remove Case From Skid (Levelers)
• Remove shipping brace that may be securing
case to skid.
• Support case to prevent tipping.
• Caution! Levelers can be damaged if case hits
floor with heavy force!
• Carefully slide unit to rear of skid and tip backward
off skid.
• Illustration may not reflect every feature or option
of your particular case.
• Case can be repositioned with pallet truck when
front lower panel is removed. Blocking may be
necessary to obtain adequate height.
Slide Skid Out
Ramp
Skid
Support case
while rolling
down ramp.
2. Remove Case From Skid (Casters)
Remove shipping brackets that secure casters to skid
• Important! Case is shipped with levelers in the
DOWN position (for stability). To prevent damage to
the case, all levelers must be raised ALL THE WAY
UP before moving unit off skid and into position.
• After levelers are raised all the way up, place ramp
up against skid (to allow case to smoothly roll off
from skid).
• Maintain support of case at all times or center of
gravity may cause case to fall.
• Roll unit to rear of skid. Roll down ramp and off skid.
To Next Page
