Wall Spacing / Rear Venting (May Not Be Applicable To Your Model)
Venting Panel: Caution! Venting is an integral part of case temperature management. Case MUST
NOT be pushed up against wall if rear venting panel is not attached!
Rear Grille: Rear grille may be removed (by removing 4 screws) for service or maintenance of
condenser unit. Return rear grille to case rear when completed.
18
WALL SPACING / REAR GRILLE & VENTING PANEL (MAY NOT BE APPLICABLE TO YOUR MODEL)
--- Case Right Side of Model B4524 ---
Approx. 1” Space Between
Rear Vent/Grille And Case
