OPTIONAL SINGLE REAR DOOR (WITH PERF. PLENUM AS PART OF DOORS) / B3632TM SHOWN
Single Rear Door (Optional):
• Illustrations below show optional roll-down
security cover intact AND removed for illustrative
purposes.
• Rear door has stainless steel skin with stainless
steel perforated plenum as part of door assembly.
• See illustrations below.
Rear Grille at Upper Section
(For Units With Top-Mounted
Condensate Packages)
Model B3632TM Is Shown. It May
Not Reflect Every Feature or
Option of Your Particular Case
Roll-Down Security Cover
Removed To Show Stain-
less Steel Plenum (Part
of Rear Door).
Rear Door
Optional Roll-Down
Security Cover
