SELF-CONTAINED HOT GAS LOOP CONDENSATE PACKAGE LAYOUTS - PAGE 2 of 2

Self-Contained Hot Gas Loop Condensate Package

• Caution: Only trained service providers are to provide maintenance and service to unit.

• Warning! Disconnect power before providing maintenance and service to unit.

--- Model B6632SC.6241 Condenser Package Component Layout ---

Sight

Glass

Filter

Dryer

Embraco®

Starter Unit

Heater Rod

Overflow Pan

Hot Gas Condensate

Coils and Pan

Condenser Coil

Housing

Condenser Coil

Fans & Housing

Compressor

CleanSweep® Housing

Condenser Pan

Caster

Condenser

Pan
