UNDERSIDE PUMP/DRAIN UNIT (FOR UNITS WITH TOP-MOUNTED SELF-CONTAINED COND. PKGS.)
Underside Pump/Drain Unit (For Top-Mounted Self-Contained Condenser Packages)
• Caution: Only trained service providers are to provide maintenance and service to unit.
• Warning! Disconnect power before providing maintenance and service to unit.
--- Model B5932TM.6785 Condenser Package Component Layout ---
Refrigeration
Lines
Piping To Route
Condensate To Top-
Mounted Condenser Pkg.
Evaporator
Pan
Electrical Outlet
(For Pump)
Pump
Drain From
Evaporator Package
