9 Technical data
9.1 Technical data - LaboForce-50
Subject Specifications
Motor output 40 W
Torque at 150 rpm > 2.6 Nm(Newton meter)
Rotational speed 150 rpm
Rotational direction Off/Counter-clockwise
Force, individual
specimens
5-30 N
Safety standards See the Declaration of Conformity
Noise level See the noise level stated for: LaboPol
Operating environment Surrounding
temperature
5 – 40°C/41 – 104°F
Humidity < 85 % RH non-condensing
Storage and transport
conditions
Surrounding
temperature
0 – 60°C/32 – 140°F
Humidity < 85 % RH non-condensing
Power supply LaboForce-50 is connected directly to LaboPol
Dimensions and weight Width 18.3 cm/7.2”
Depth 43.5 cm/17.1”
Height 51.6 cm/20.3” (measured from the
preparation disc)
Weight 14.5 kg/32 lbs
9.2 Diagrams - LaboForce-50
Title No.
LaboForce-50/LaboForce-Mi, Block diagram 16353050 B
LaboForce-50/LaboForce-Mi, Circuit diagram 16353100 D
18 LaboForce-50
9 Technical data
