1. Cut the packing tape on the top of the box.
2. Remove the loose parts.
3. Remove the unit from the box.
5.2 Check the packing list
Optional accessories may be included in the packing box.
The packing box contains the following items:
Pcs. Description
1 LaboForce-50
1 Spacer and 2 M4 screws for mounting on LaboPol-30 and LaboPol-60
1 Spacing disc
1 Allen key for mounting the specimen mover plate
1 Instruction Manual set
5.3 Installation - LaboForce-50
Install the specimen mover in the connection hole of the machine.
Note
This device must be mounted securely on the machine.
Note
Do not use the speed control knob on the control panel to move the specimen mover.
Procedure - LaboPol-20
1. Remove the plastic disc protecting the communication cable.
2. Connect the communication cable on the column to the
connection port on the machine.
10 LaboForce-50
5 Installation
