4.1.2 Individual Replacement Instructions

NOTE: Before removing any component in the X-7000,

the Console Cover must be removed (refer to sec-

tion 4.2).

To remove and repair any of the following components,

proceed to section 4.3 (Power Source Components):

• Control Board (4.3.1)

• Lamp Ballast (4.3.2)

• AC Inlet Board (4.3.3)

• Ballast Fan (4.3.4)

To remove and repair any of the following components,

proceed to section 4.4 (Light Source Components):

• Bulb (4.4.1)

• Bulb Fan (4.4.2)

• Shutter (4.4.3)

• Hot Mirror (4.4.4)

• Motor Mount (4.4.5)

• Motor (4.4.6.1)

• Integrating Rod (4.4.6.2)

To remove and repair any of the following components,

proceed to section 4.5 (Front Panel Components):

• Jaw Handle (4.5.1)

• Potentiometer Knob (4.5.2)

• Front Panel (4.5.3)

• Jaw Assembly (4.5.4)

• Power Switch (4.5.5)

• Display Board (4.5.6)

To remove and repair any of the following components,

proceed to section 4.6 (Rear Board Components):

• Fuses (4.6.1)

4.2 CONSOLE COVER REMOVAL

Tools Required:

Basic Tool Kit

• Remove power cord.

• On the back of the unit, remove the two screws attaching

the console to the unit.

• Open the lamp door latch on the side of the unit and

open the door.

• Slide the cover back, then lift off.
