Sukup Sweepway - Page 11

Dimensions
11
8” SWEEPWAY DIMENSIONS
BIN DIA.
A
B
C
D
E
F
G
15'
17
35
125
99.5
189.5
162.5
184
15' 6"
14
32
125
99.5
189.5
162.5
184
16" 5" (5M)
14.5
32.5
131
97
195.5
168.5
190
18'
17.5
35.5
143.5
100
208
181
202.5
18' 7"
14
32
143.5
96.5
208
181
202.5
19' 8" (6M)
14
32
150
96.5
214.5
187.5
209
21'
18
36
162
100.5
226.5
199.5
221
21' 8"
14
32
162
96.5
226.5
199.5
221
22" 11" (7M)
14.5
32.5
170
97
234.5
207.5
229
24'
18
36
180
100.5
244.5
217.5
239
24' 9"
13.5
31.5
180
96
244.5
217.5
239
26' 3" (8M)
14.5
32.5
190
97
254.5
227.5
249
27'
19
37
199
101.5
263.5
236.5
258
27' 10"
14
32
199
96.5
263.5
236.5
258
29' 6" (9M)
14
32
209
96.5
273.5
246.5
268
30'
20
38
218
102.5
282.5
255.5
277
31'
14
32
218
96.5
282.5
255.5
277
33'
20
38
236
102.5
300.5
273.5
295
34'
14
32
236
96.5
300.5
273.5
295
36' (11M)
20
38
254
102.5
318.5
291.5
313
37' 1"
13.5
31.5
254
96
318.5
291.5
313
42'
14
32
284
96.5
348.5
321.5
343
42' 8" (13M)
14
32
288
96.5
352.5
325.5
347
43' 3"
14
32
291.5
96.5
356
329
350.5
48'
14
32
320
96.5
384.5
357.5
379
49' 3" (15M)
15
33
328.5
97.5
393
366
387.5
54'
14
32
356
96.5
420.5
393.5
415
55' 8"
14
32
366
96.5
430.5
403.5
425
60'
14
32
392
95.5
456.5
429.5
451
61' 10"
14
32
403
96.5
467.5
440.5
462
10” SWEEPWAY DIMENSIONS
BIN DIA.
A
B
C
D
E
F
G
24'
30
48
192
142
286
236.5
258
24' 9"
25.5
43.5
192
137.5
286
236.5
258
26' 3" (8M)
24
42
199.5
136
293.5
244
265.5
27'
31
49
211
143
305
255.5
277
27' 10"
26
44
211
138
305
255.5
277
29' 6" (9M)
26
44
221
138
315
265.5
287
30'
32
50
230
144
324
274.5
296
31'
26
44
230
138
324
274.5
296
33'
32
50
248
144
342
292.5
314
34'
26
44
248
138
342
292.5
314
36' (11M)
32
50
266
144
360
310.5
332
37' 1"
25.5
43.5
266
137.5
360
310.5
332
42'
26
44
296
138
390
340.5
362
42' 8" (13M)
24
42
298
136
392
342.5
364
43' 3"
26
44
303.5
138
397.5
348
369.5
48'
26
44
332
138
426
376.5
398
49' 3" (15M)
27.5
45.5
341
139.5
435
385.5
407
54'
26
44
368
138
462
412.5
434
55' 8"
26
44
378
138
472
422.5
444
60'
26
44
404
138
498
448.5
470
61' 10"
26
44
415
138
509
459.5
481
IMPORTANT:
Dimensions are
based on nominal
bin diameters
listed and provide
approximate
measurements
for planning and
layout purposes.
Table 6 – Unload
system dimensions
for 10” Sweepway
Table 5 – Unload
system dimensions
for 8” Sweepway
