Sukup Sweepway - Two Motor Drive; One Motor Drive

Installation
30
Two Motor Drive (Standard Equipment)
To aid in part identification during assembly, see Pages 52-53.
1. Follow Steps 1-17 in Basic Vertical Auger Assembly Instructions.
2. Mount motor (motor and motor pulley not included) onto horizontal motor mount using four 3/8 x 1-1/2"
bolts, lock washers, flat washers and nuts. Motor uses 3.4" motor pulley.
3. Reinstall brackets and inner shield section.
4. Mount large pulley onto horizontal shaft. Place 1/4" key in slot of pulley. Align pulley with motor pulley.
Tighten setscrews.
5. Install belts provided and tighten to proper tension by adjusting bolt under horizontal motor mount.
See belt-adjusting instructions on Page 34.
6. Mount 3.4" motor pulley onto vertical motor. Mount motor to vertical motor mount plate, using four 3/8
x 1-1/2" bolts, nuts, washers and flat washers.
NOTE: Shields for vertical auger are attached upside-down at factory to avoid damage during shipping.
They must be rotated 180° during field installation.
7. Mount 9" pulley onto bottom vertical shaft. Place 1/4" key in slot of pulley. Align with motor pulley and
tighten setscrews.
8. Install belt(s) onto pulleys and adjust to proper tension. See belt-adjusting instructions on Page 34.
9. Ensure all safety shields are in place and bolts are tight.
One Motor Drive (Optional Equipment)
To aid in part identification during assembly, see Pages 53-54.
1. Follow Steps 1-17 in Basic Vertical Auger Assembly Instructions.
2. Slide large pulley (35) onto shaft extending from horizontal unload tube with hub side of pulley out.
Place 1/4" key (36) in slot on pulley.
3. Slide 50B15 sprocket (62) on shaft protruding from horizontal unload tube with hub side away from
pulley.
4. Slide 50B15 sprockets (56) on each shaft of gearbox and on bottom shaft of vertical auger. Place 1/4"
key in slots of all sprockets and align. Tighten setscrews.
5. Place short #50 chain and connector link on sprocket on bottom of gearbox and sprocket on bottom of
vertical auger. Chain can be tightened by adjusting gearbox mounting bolts. Align.
6. Mount motor onto mounting plate (11) with 3/8 x 1-1/4" bolts, nuts, washers, and flat washers. Mount
3.4" motor pulley. Align pulleys and tighten setscrews. Place belts (39) on pulleys and adjust tension
by adjusting under motor mount plate. See belt-adjusting instructions on Page 34.
7. Place long #60 chain and connector link on sprocket on front of gearbox and on sprocket on end of
horizontal unload tube. Adjust tension by raising or lowering idler sprocket (64). Align.
8. Ensure all safety shields are in place and bolts are tight.
