Installation
SWEEPWAY POWERHEAD OPTIONS
Horizontal with Single Motor Drive
To aid in part identification during assembly, see Pages 48-49.
1. Slide connector sleeve onto unloading tube and loosely attach with 3/8 x 3" bolts, lock washers and
nuts. See Pages 35-37 for instructions on installation of sump openers.
2. Remove safety shield sections (6, 8) and brackets (7) from powerhead assembly. Slide powerhead
tube into connector sleeve so unload auger shaft protrudes through flange bearing (9). Slide
powerhead on completely so that it contacts unloading tube.
3. Rotate powerhead assembly to level position and tighten bolts on connector sleeve.
4. Slide locking collar (26) over auger shaft protruding from unloading tube and lock onto flange
bearing. Tighten setscrew on locking collar.
5. Mount 3.4" motor pulley onto motor shaft. Secure with key and setscrew.
6. Mount motor onto motor mount plate (4) with 3/8 x 1-1/2" bolts, nuts, lock washers and flat washers.
7. Re-attach brackets (7) and inner shield (8).
8. Attach pulley (25) to shaft extending from unload tube. Place 1/4" key (27) in slot on pulley and align
with motor pulley. Tighten setscrew.
9. Place belts (28) on pulleys. Tension may be adjusted by tightening bolt on bottom motor mount plate.
See belt-adjusting instructions on Page 34.
10. Place outer safety shield (6) over pulley and tighten bolts. KEEP SHIELD IN PLACE AT ALL TIMES!
