Sukup Sweepway - Page 44

Parts/Assemblies
44
UNLOAD TUBE
*Varies with bin size
REF. #
DESCRIPTION
QTY.
6” PART #
8” PART #
10” PART #
1
Intermediate sump, w/ rollers
*
E5390
E5398
E5395
2
Independent int. sump, 10", 2018
1
---
E53981
E53951
3
Independent int. sump slide gate assy., 10"
1
---
E53987
E53963
4
Intermediate sump slide gate assy., 6" & 8"
*
E5409
E5409
E5409
5
Shaft collar, 7/8", no set screw
*
E5448
E5448
E5448
6
Shaft collar, 7/8", w/ bolt
1
E5449
E5449
E5449
7
Clutch rod
1
*
*
*
8
Center sump pull rod
1
*
*
*
9
Independent intermediate sump pull rod
1
---
*
*
10
Intermediate sump pull rod
1
*
*
*
11
Tab, 1-1/2" x 1"
2
F4415-01
F4415-01
F4415-01
12
Screw, 5/16 – 18 x 3/4"
*
J0520
J0520
J0520
13
Screw, 3/8 – 16 x 1”
*
J0606
J0606
J0606
14
Lock nut, 5/16” – 18
*
J1010
J1010
J1010
15
Hex nut, 1/2" – 13
*
J1040
J1040
J1040
16
Shaft collar, 7/8”
*
J1330
J1330
J1330
