Sukup Sweepway - Page 51

Parts/Assemblies
51
BASIC VERTICAL AUGER
REF. #
DESCRIPTION
QTY.
6" PART #
8" PART #
10" PART #
1
Rollpin, 5/16" x 1-3/4"
1
J1495
J1495
J1495
2
Top shaft
1
E58091
E97711
E58243
3
Hex nut, 7/16" -14
2
J1035
-----
-----
Hex nut, 1/2" – 13
2
-----
J1040
J1040
4
1” flange bearing w/ lock collar
1
J0003
------
------
1-1/4" flange bearing, w/ lock collar
1
------
J0010
J0010
5
Split lock washer, 7/16"
2
J1210
J1210
-----
Split lock washer, 1/2"
2
-----
-----
J1215
6
Bolt, 3/8 - 16 x 1"
12
J0606
J0606
-----
Bolt, 7/16" - 14 x 1"
12
-----
-----
J0695
7
Bearing end plate
1
E5676
E5776
E5659
8
Bolt, 7/16 - 14 x 1.25"
2
J0700
-----
-----
Bolt, 1/2 - 13 x 1.5"
2
-----
J0730
J0730
9
Split lock washer, 3/8"
2
J1205
J1205
-----
Split lock washer, 7/16"
2
-----
------
J1210
10
Hex nut, 3/8” – 16
12
J1020
J1020
-----
Hex nut, 7/16" – 14
12
-----
-----
J1035
11
Top outlet spout
1
E5812
E5813
E5785
12
2-1/2’ truck spout
1
E5814
E5815
E5787
13
Connector sleeve
3
E5423
E5424
E5425
14
30" support bracket (bipod)
2
E5800
E5801
E5786
15
12’ galvanized auger tube
1
E5842
E5843
E57842
16
Screw, 5/16 - 18 x 1/2”
8
J0519
J0519
J0519
17
Rack & pinion opener
1
-----
E5919
E5969
18
Hex nut, 5/16” – 18, (Not shown)
2
J1002
J1002
J1002
19
Decal, Keep Away from Moving Parts
1
L0284
L0284
L0284
20
Decal, Do Not Enter Bin, Keep clear of augers
1
L0258A
L0258A
L0258A
21
Decal, Safe Operation
1
L0281
L0281
L0281
22
Locking collar, 1”
1
J0067
------
------
Locking collar, 1-1/4”
1
------
J0068
J0068
23
16' vertical auger w/ flinger & shafts
(See Page 88 for flighting, shafts & tubes)
1
E5846
E5847
E57833
24
Bottom shaft, w/ keyway (Not shown)
1
E58081
E9751
E58252
25
Decal, Shield Missing (Not shown)
1
L0271
L0271
L0271
26
Outer vertical shield
1
E5977
E5977
E5977
27
Inner vertical shield (Not shown)
1
E5976
E5976
E5976
28
Vertical shield bracket (Not shown)
2
E5978
E5978
E5978
29
Outer horizontal shield
1
E5973
E5973
E5973
30
Inner horizontal shield (Not shown)
1
E5972
E5972
E5972
31
Horizontal shield bracket (Not shown)
2
E9316
E9316
E5974
32
Screw, 5/16 – 18 x 1” (Not shown)
6
J0527
J0527
J0527
33
Split lock washer, 5/16” (Not shown)
6
J1200
J1200
J1200
34
Flat washer, 5/16”, (Not shown)
6
J1111
J1111
J1111
