Sukup Sweepway - Page 57

Parts/Assemblies
57
TOP DRIVE
*QTY. depends on size
REF. #
DESCRIPTION
QTY.
6" PART #
8" PART #
10" PART #
1
Top power housing spout
1
E5929
E5933
E57851
2
Bearing plate
1
E5676
E5776
E5659
3
Hex nut, 3/8" – 16
4
J1020
J1020
-----
Hex nut, 7/16" – 14
4
-----
-----
J1035
4
Flange bearing
2
J0003
J0010
J0010
5
Locking collar
3
J0067
J0068
J0068
6
Bolt, 7/16 - 14 x 1-1/4"
2
J0710
-----
-----
Bolt, 1/2 - 13 x 1-1//2"
2
-----
J0730
J0730
7
Split lock washer, 7/16"
2
J1210
-----
-----
Split lock washer, 1/2"
2
-----
J1215
J1215
8
Hex nut, 7/16" – 14
2
J1035
-----
-----
Hex nut, 1/2" – 13
2
-----
J1040
J1040
9
Pulley, 9" OD 2 groove
1
J0365
J0366
J0366
10
Bolt, 3/8 - 16 x 1"
4
J0606
J0606
-----
Bolt, 7/16 - 14 x 1"
4
-----
-----
J0695
11
Rollpin, 5/16 x 1-3/4”
1
J1495
J1495
J1495
12
Bolt, 3/4 - 10 x 6”
1
J0824
J0824
J0824
13
Hex nut, 3/4” – 10
1
J1051
J1051
J1051
14
Hinged motor mount, small
1
E5746
E5746
E5746
15
Pivot rod, small
1
E5744
E5744
E5744
16
Hairpin clip, .120 x 2.5
1
J5412
J5412
J5412
17
Machine bushing, 3/4"
*
J1260
J1260
J1260
18
Split lock washer, 3/8"
4
J1205
J1205
-----
Split lock washer, 7/16"
4
-----
-----
J1210
19
Split lock washer, 3/8"
4
J1205
J1205
J1205
20
Hex nut, 3/8” – 16
5
J1020
J1020
J1020
21
Square key, 1/4" sq.
1
E5720
E5720
E5721
22
Pulley, 3/2 P.D., 1-1/8 DBL, cast
1
J0317
J0317
J0317
23
Belt, BX42 (6 & 8") - BX46 (10")
2
J0200
J0200
J0215
24
Vertical shield bracket
2
E9316
E9316
E5974
25
Inner vertical shield
1
E5972
E5972
E5972
26
Bolt, 5/16 - 18 x 1”
8
J0527
J0527
J0527
27
Flat washer, 5/16"
8
J1111
J1111
J1111
28
Split lock washer, 5/16"
4
J1200
J1200
J1200
29
Screw, 5/16 – 18 x 1/2"
8
J0519
J0519
J0519
30
Outer vertical shield
1
E5973
E5973
E5973
31
Top power shaft
1
E58092
E54153
E58244
32
Decal, Do Not Enter Bin, Keep Clear of Augers
1
L0258A
L0258A
L0258A
33
Decal, Danger, Replace Missing Shield
2
L0271
L0271
L0271
34
Decal, Safe Operation
2
L0281
L0281
L0281
35
Decal, Keep Away From Moving Parts
2
L0284
L0284
L0284
36
Decal, Sukup logo (Not shown)
1
L0317
L0317
L0317
37
Top drive spacer
1
M3239
E57415
E57415
38
Rack & pinion opener
1
-----
E5919
E5969
39
Auger tube for 16' vertical
1
E5842
E5843
E57842
40
Connector sleeve
3
E5423
E5424
E5425
41
16’ vert. auger w/ flinger & shafts (Not shown)
1
F4750
E58471
E57836
42
Support bracket, 30" (bipod)
1
E5800
E5801
E5786
43
Truck spout, 2-1/2'
1
E5814
E5815
E5787
44
Bolt, 3/8 - 16 x 1”
6-8
J0606
J0606
J0606
45
Hex nut, 3/8” - 16
6-8
J1020
J1020
J1020
46
Horizontal shield bracket (Not shown)
2
E9316
E9316
E5974
47
Inner horizontal shield (Not shown)
1
E5972
E5972
E5972
48
Outer horizontal shield
1
E5973
E5973
E5973
49
Bottom shaft (Not shown)
1
F48101
G73291
F48342
