Sukup Sweepway - Page 85

Parts/Assemblies
85
REAR CARRIER WHEEL
BIN COLLAR
REF. #
DESCRIPTION
QTY.
PART #
Rear carrier wheel kit
-
E6099
1
Rear carrier wheel bracket, left
1
E7741
2
Rear carrier wheel bracket, right
1
E7740
3
Rubber wheel, 6”, w/ bushing
1
J7271
4
U-bolt, 3/8" - 16
4
J0644
5
Bolt, 3/8 - 16 x 3-1/4"
1
J0663
6
Flat washer, 3/8"
2
J1117
7
Hex nut, 3/8" -16
8
J1020
8
Split lock washer, 3/8"
8
J1205
9
Lock nut, 3/8" - 16
1
J1025
REF. #
DESCRIPTION
QTY.
PART #
1
Clutch latch
1
E5408
2
Machine bushing, 1/2" x 18ga
3
J1250
3
Shaft collar, 1/2"
1
J1320
4
Cotter pin, 1/8 x 1"
1
J1420
5
Picker pin, 1/2 x 1-1/2”
1
J1550
6
Pawl spring
1
J2360
