3.3 Connection
A typical 16E / 16E-H / 16E-P Spray Gun installation is shown in the
following illustration.
• For a complete list of available hose packages, refer to the parts
list, PL 96151.
• Instructions for auxiliary equipment, identify the hoses that are
required and optionally available for those components.
5k_connect
3GF
3AF
O
2
Fuel
6A
16E
Fuel Gas
Oxygen
3GRO
3GRA/3GRP
Fuel Gas
Oxygen
Air
Air
2W
Wire
Compressed
4AC
Air Supply
