Sulzer 16E - Central Housing

16E / 16E-H / 16E-P Spray Gun
58
MAN 96150 EN 01
6.9.6 Central Housing
The central housing assembly (129) should not be disassembled
unless absolutely necessary to replace parts. The housing pump (130)
requires critical alignment with the countershaft. This alignment can
only be done properly by Sulzer Metco as part a factory overhaul.
CAUTION
Do not remove housing
pump from central
housing.
129
130
131
132
133
16e_central_housing
