9
EN 5675-L
6�2 Design features PE3 (version with cooling jacket)
1 Stainless steel lifting hoop 9b Leakage sensor (DI) 60 Hz 19 Lower bearing - double row
2 Lid assembly 10 Lipseal 20 Inspection chamber
3 Cable gland 11 Seal holding plate 21 Coolant impeller
4 Upper bearing - cylindrical roller 12 Mechanical seals 22
bearing 13 Venting plug 23 Coolant drain plug /
5 14 Terminal block pressure test point
6 Cooling jacket 15 Pressure test point 24 Seal chamber
7 Motor housing 16 Upper bearing housing 25 Volute
8 Lower bearing housing 17 Motor with thermal sensors 26 Impeller - Contrablock version
9a Leakage sensor (DI) 50 Hz 18 Stainless steel shaft 27 Bottom plate adjustment screw
1
2
3
4
5
6
7
8
9a
14
15
5
17
21
18
19
9b
13
20
26
24
23
22
27
25
10
11
12
16
