Sulzer XFP 100E-VX - Dry-installed

17
EN 5675-L
9�3�2 Dry-installed
Horizontal


Vertical
1
2
3
4
5
6
8
7
9
10
1 Control panel
2 Discharge line
3 Gate valve
4 Non-return valve
5 Power cable from motor to
control panel
6 Pump
7 Collection sump
8 
9 
10 Gate valve
1
2
3
4
5
6
8
7
9
10
