Basic Operation 4-3
FIG 4-2
4-2 ACTION MENU
The confidence test performs a quick electrical and mechanical test of the cutter to make sure
that the cutter is fully operational. A media sheet of at least A3/B-size should be used for this
plot. This test is always cut at the left side of the loaded media.
This menu can be used when loading sheet material. During loading, the maximum material
length can be set.
This action is explained in section 1.5.2.
The RECUT instruction recuts the last file, which was sent to the cutter (provided it fitted into
the buffer). Press to execute.
The RESET instruction performs a complete reset of the cutter. Press to execute a reset.
Load
Replot
Load extended
Confidence test
Reset
Actions
