52 SUNFAR E300 SERIES
Data return: data correct set.
Slave
return
Heade
r
Slave
addr.
Slave
correspond
State
feedback
Data type
Data
addr.
Set data
Check
sum
Tai l
Digit 1 2 1 2 1 2 4 4 1
2A 30 30 30 30 33 30 30 31
30 31
46 34
30 32
35 46
0D
E.g.
5A 00 00 00 00 03 00 00 01
00 00
01 F4
00 00
00 F9
0D
Explain Heade
r
0 slave
return
Slave receive
data
Slave stop
state
F0
Parameter
unit
F0.1
Set data
50.0HZ
Adding
hex
Tai l
1.4.5 Send control order (order type 4)
Data return: set slave 0 inverter FWD running freq 10.0 Hz.
Master send Header Slave addr. Order type Operation order Set data Check sum Ta il
Digit 1 2 1 2 4 4 1
2A 30 30 34 31 31
30 30
36 34
30 31
43 30
0D
E.g.
5A 00 00 04 00 11
00 00
00 64
00 00
00 79
0D
Explain Header Addr. 00 4 order FWD with freq set Set freq 10.0 Hz Adding hex Tail
Data return: 0 inverter receives data normally.
Slave
return
Header
Slave
addr.
Slave
correspond
State
feedback
0
Monitor
item
Running data
Check
sum
Tai l
Digit 1 2 1 2 1 2 4 4 1
2A 30 30 30 30 31 30 30 30
30 30
36 34
30 32
34 42
0D
E.g.
5A 00 00 00 00 01 00 00 00
00 00
00 64
00 00
00 65
0D
Explain Header
0
slave
return
Slave
receive
data
Slave
FWD
running
Fixed
data
Present
display
monitor
d-0
Data set
successfully
Adding
hex
Tai l
