Specifications
Table for Clutch Motor S/M Spin Number
Table for sewing machine rotation number in the event of a clutch motor (external diameter of hand pulley: 80mm)
Computation is according to anumber of regularity rotation.
External diameter of the
sewing machine pulley (mm)
60 65 70 75 80 85 90 95
Number of sewing machine rotation
(rpm)
2583 2799 3014 3229 3445 3665 3875 4091
Usage Heavy weight Materials(Jeans) Light Materials
Stitch Length (mm) 2-4.2 1.1-3.1
Needle Bar Stroke (mm) 35 27
Feed Dog Height (mm) 1.2 0.9
Needle TVX5#Nm22 TVX64NY#11PSU
Attachment 1/4XH, 1/4X 1/4M
Puller Belt-type , Roller Type Puller Roller Type Puller
Presser Foot Climb Sensor O X X X
Presser Bar Pneumatic Type O X O X
Pulley Size X 60Hz : 80, 50Hz : 100 X 60Hz : 80, 50Hz : 100
Main Motor AC Servo (FORTUNA4)
Clutch 2P 60Hz 400W
AC Servo (FORTUNA4)
Clutch 2P 60Hz 400W
Clutch 2P 50Hz 400W Clutch 2P 50Hz 400W
Max. Sewing Speed (spm) 4000 4000 (default setting: 3500) 4000 4000 (default setting: 3500)
Lubrication Oil tank type
Model SC 8200J/01 SC 8200J/02 SC 8200L/01 SC 8200L/02
Power : Main Shaft Motor for Clutch (SMC-1701D), Hand Pulley 80
In case of 3500 RPM : 2P 60HZ(1-phase high-speed) → Motor pulley 80, V belt M Type 43 inch
2P 50HZ(1-phase high-speed) → Motor pulley 100, V belt M Type 44 inch
