41
18) Ascending Momentum of the Ruller
* LRP Type(PART NO.77), SRP Type(PART NO.71)
-> the quantity of motion in case of working with a
machine (13m/m).
* The quantity of motion when part no.29(manual lever) is
lifted by hand (15m/m~25m/m)
19) Bearing Replacement
- Parts Life [LRP Type (PART NO.54, NO.57), SRP Type
(PART NO.91, NO.95) 5R BEARING]
Parts can be used for 2.5 to 3.5 years although there are
some gaps according to the workload.
-Replacement Time
Replace them when the machine stitch mismatches to the
stitch of the puller due to the pulling malfunction with
long use.
20) Breakdown of TENSION DISK & E-RING
LRP Type(PART NO.62~NO.76), SRP Type(PART NO.51~NO.65)
- Engine structure has the pulling function of piller and built-in
grease, does not need oil.
13m/m
15m/m~25m/m
Need not use oil due to the oilless bearing. In case of refueling unnecessary oil, the stuff can be tainted so
the use of oil is prohibited.
Caution
If the thread winds around the engine structure or the parts are damaged by mistakes, the function of puller
can be out of order so do work with care.
(The damage caused by a careless worker cannot be repaired for free.)
Caution
