5.9) Load Frame Installation
1) Fix the stacker (ass’y) ① to the stacker holder ② with
bolts using the saddle stopper ③.
2) Connect the cable ④ and the pneumatic hose ⑤ to the
solenoid valve ⑥ of the stacker.
3) Fix the stacker safety guide ⑦ using bolts.
③
②
⑤
①
⑥
④
⑦
