SunStar SJS/A-PS/A User Manual

6
11
Machine Type and Specifications
S
UNSTAR JEAN S
YSTEM SERIES
SUB CLASS
POCKET SETTER
SJS/A-PS/A Series Model Label Structure
SJS/A-PS/A
Machine Type
Sewing Scope
Sewing Speed
Stitch Length
Needle
Needle Bar Stroke
Presser Foot Stroke
Presser Foot Lift
Trimmer
Emergency Stop Function
Hook In Use
Memory
Graphic OP
Lubrication
Pneumatic Pressure
Voltage
Motor
Power consumption
Direct Drive, High Speed, 1-Needle, Lock-Stitch M/C
250mm(X)×250mm(Y)
3600 spm (Stitch length: 3mm or below)
0.1mm∼6mm
DP×17 #20 (#18∼22)
34.6mm
Standard 4mm (0.5~10mm)
20mm
Mounted
Available
Double-capacity Rotary Hook
USB Flash Drive
Options
Automatic
120Nℓ/min.
Rated supply voltage ± 10% 50/60 Hz
MAIN MOTOR 500W AC SERVO MOTOR
X-MOTOR 1Kw AC SERVO MOTOR
Y-MOTOR 750W AC SERVO MOTOR
600VA
