45
Loosen the two bolts ① with the wrench. Loosen the four
bolts ② with the wrench in the same way. Disassemble and
take out the bracket ③ and the push device ④.
01
Loosen the six socket set screws ① with the wrench and
disassemble the clamp base ②.
02
1
3
1
2
2
4
7.17) Former Clamp Replacement
