6.2) Needle Installation
Loosen the needle fixing screw on the needle bar and put
the long groove of the needle headed to the left. Insert the
needle until the needle head touches the end of the needle
hole and fix the needle with the screw.
6.3) Upper Thread Placement
Locate the thread take-up lever at the highest position and place the upper thread as in the figure.
Needle Fixing Screw
Needle
