44
7.16) Pneumatic System Circuit Diagram
SJS/A-PS/A(Pocket Setter)
Pneumatic System Circuit Diagram
(Prepared by: Han Du-Gong/ Date: Dec. 28, 2006)
Outer clamp cylinder
Inner clamp
cylinder
Solenoid
Valve
Presser Foot
Lift Cylinder
Thread Release
Cylinder
Feed
Cylinder
Stacker Feed
Cylinder
Pocket Setter
(Jig) Up/Down
Stacker Short
Shaft Cylinder
Stacker Long
Shaft Cylinder
Air wiper
Filter
Filter
Air
