42
3) Assemble the upper feed plate① with the block⑤ as in the figure. Use the two fixing screws③ to fix the shaft. Fix
the lower feed plate② to the body bracket⑥ using the two fixing screws④ as in the figure.
①
⑤
⑥
④
③
②
