20
4)
Open the hook cover and supply oil till the shuttle
race ring is surrounded by oil. Put the hook cover
back on after finishing.
5)
Supply sillicon oil into the sillicon oil tank which is
installed on the right side of the arm.
5.2) needle
5.2.1) Needle Attachment
Unfasten the needle fixing screw on the needle bar.
Then, with the needle groove facing forward, push
the needle until the upper end touches the needle
hole of the needle bar. Fix the needle in with the
needle fixing screw.
For safety, keep the hook cover covered during operating.
Caution
Shuttle Race Ring
Hook Cover
Screw
Needle
To Next Page
