PNEUMATIC HOOK-TYPE CLOTH FEED
11.1) Mechanical specifications
As in the figure, the cloth feed area is different from the regular type.
11.2) How to operate
A. When the pallet is inserted into the coupling, the sensor detects the pallet, and the presser foot automatically
descends to fix it.
B. When the left foot pedal② is pressed, sewing begins. In order to separate the pallet from the fixing device, press
the right foot pedal①.
C. When sewing is complete, the pallet is automatically separated from the fixing device.
①②
