SunStar SPS/E-1306 Series User Manual

44
99
SPS/E-1306(1507)-HS(GS)-20(21, 22,22-1,23)
9.1) Machine Specifications
Series type
Sewing Area
Sewing Speed
Stitch Length
Needle
Needle Bar Stroke
Hook
Bobbin Case
Bobbin
Presser Foot Stroke
Lifting Amount of Presser Foot
Lifting Amount of Feeding Frame
Feeding System
Emergency Stop Function
Pattern Select Function
Memory
Memory Backup
2nd Origin Function
Maximum Speed Limit
Sefety Device
Main Motor
Power Consumption
Recommended Temperature
Recommended Humidity
Power
Air Pressure
SPS/E-1306 SPS/E-1507
130mm×60mm 150mm×70mm
Max. 2,700spm (Stitch Length : 3mm or Less)
0.1 ~ 12.7mm (Min. limit of resolution: 0.05mm)
DP×17, DP×5
41.2mm
Semi-Rotary Large Shuttle
Bobbin Case for Semi-Rotary Large Shuttle Hook
Bobbin for Large Shuttle Hook
Standard 4mm [0.5~10mm]
Max. 20mm
Max. 30mm
Full Closed Pulse Motor-based Feed
Available During Sewing Operation
Pattern No. can be Selected from No.1 to No.999
USB Flash Drive
The Working Point is Stored in the Memory when the Machine Stops Abnormally
Another Origin Point can be Set by Using Jog Key
The Maximum Speed can be Limited from 200 to 2,700 spm
Emergency Stop Function, Maximum Speed Limit Function
Direct Drive 550W AC Servo Motor
600VA
5。C ~ 40。C
20% ~ 80%
ф : 100~240V, 3ф : 200~440V, 50/60Hz
4 ~ 4.5 kgf/cm
2
(0.39~0.44 Mpa)
