5.2.2 Configuration specification
Machine specification SWE210F
A、 Wheel track 3465
B、 Track total length 4450
C、 Platform distance to ground 1060
D、 Platform slewing radius 2750
E、 Upper structure width 2710
F、 Track gage 2200
G、 Chassis width 2800
H、 Track width 600
I、 Chassis distance to ground 470
J、 Cab roof height 2965
L、 Transportation length 9590
M、 Boom height 3045
Unit：mm
