C2SBM-Q User’s Manual
Motherboard Layout
Important Notes to the User
• Jumpers not indicated are for test purposes only.
• See Chapter 2 for detailed information on jumpers, I/O ports and JF1 front
panel connections.
• " " indicates the location of "Pin 1.'
Overclocking Considerations
Warning: Please be aware of the following conditions when "overclocking" is
used: Setting a high CPU FSB speed (overclocking), DRAM frequency or se-
lecting a high CPU V-Core voltage, memory voltage, chipset voltage, ICH chipset
voltage, or FSB termination voltage may result in system instability. If this occurs,
revert to the default settings. In addition, extra fans may be needed for proper system
cooling. The C2SBM-Q offers the option of "overclocking" however, Supermicro is
not responsible for any damage caused by the use of overclocking.
