2-7 Jumper Settings
Explanation of
Jumpers
To modify the operati on of the
motherboard, jumpers can be used
to choose between optional settings.
Jumpers create shorts between two
pins to change the function of the
connector. Pin 1 is identified with a
square solder pad on the printed circuit
board. See the motherboard layout
pages for jumper locations.
Note: On two pin jumpers, "Closed"
means the jumper is on and "Open"
means the jumper is off the pins.
GLAN Enable/Disable
JPL1 enables or disables the GLAN
Port on the motherboard. See the
table on the right for jumper settings.
The default setting is enabled.
GLAN Enable
Pin# Definition
1-2 Enabled (*default)
2-3 Disabled
A. GLAN Port1 Enable
A
To Next Page
