Chapter 1: Introduction
1-7
Onboard I/O
• Built in ICH9DO SATA Controller, four connectors for up to four devices
Note: The onboard SATA 0,1,4,5 may be displayed as SATA 0,1,2,3 as the order
on the silkscreen may differ from the one shown in the BIOS (see Chapter 4).
• Four Fast UART 16550 compatible serial port/header
• Intel 82566DM Gigabit Ethernet controller
• PS/2 mouse and keyboard ports
• IT8213 ITE controller supports up to two IDE devices
• 11 USB 2.0 ports for a speed of up to 480Mbps
• Realtek ALC 883 7.1 Channel High Definition Audio (HDA) codecs supports 10
DAC Channels
• Built-in GMCH and Onboard VGA Connector
Other
• Trusted Platform Module (TPM) support
• Wake-on-LAN
• Wake-on-Ring (WOR)
• System Bus Clock Frequency Selection (Overclocking) Support
• Suspend-to-RAM
• Onboard +5V Standby Power Warning LED ("LE1")
• Pb Free
CD Utilities
• BIOS flash upgrade utility
• Drivers and software for Intel Q35 chipset utilities
Dimensions
• Micro ATX form factor, 9.6" x 9.6" (243.8 mm x 243.8 mm)
