4-18
C2SBM-Q User's Manual
Modulation (PWM). Select “Workstation” if your system is used as a Workstation.
Select “Disable” to disable the fan speed control function to allow the onboard
fans to constantly run at full speed (12V). The Options are: 1. Disable and 2.
Optimized for Workstations with 4-pin.
Note:
In the Windows OS environment, the Supero Doctor III settings take pre-
cedence over the BIOS settings. When first installed, Supero Doctor III adopts
the temperature threshold settings previously set in the BIOS. Any subsequent
changes to these thresholds must be made within Supero Doctor, since the
SD III settings override the BIOS settings. For the Windows OS to adopt the
BIOS temperature threshold settings, please change the SDIII settings to be
the same as those set in the BIOS.
Voltage Monitoring
The following items will be monitored and displayed:
Vcore A
12
V
V_DIMM
5V
3.3
V
-12V
3V Standby
Vbatt.
