1-6
X10DRU-i+ Motherboard User’s Manual
(FP) USB 2 (3.0) Type A USB 3.0 header for front chassis access
(FP) USB 3/4 (3.0) Front-accessible USB 3.0 connections 3/4
VGA Backpanel VGA Port (JVGA1)
X10DRU-i+ LED Indicators
LED Description State Status
BMC_HB_LED1 BMC Heartbeat LED (Green: Blinking) BMC Normal
LED1 Rear UID LED (Blue: On) Unit Identied
HDD_LED1 HDD Heartbeat LED (Blinking) HDD Normal
LED2 Onboard PWR LED On System Power On
LED_A1 Memory Fault Detect LED for memory slot A1: Red: On Memory Error(s)
LED_A2 Memory Fault Detect LED for memory slot A2 Red: On Memory Error(s)
LED_A3 Memory Fault Detect LED for memory slot A3: Red: On Memory Error(s)
LED_B1 Memory Fault Detect LED for memory slot B1: Red: On Memory Error(s)
LED_B2 Memory Fault Detect LED for memory slot B2: Red: On Memory Error(s)
LED_B3 Memory Fault Detect LED for memory slot B3: Red: On Memory Error(s)
LED_C1 Memory Fault Detect LED for memory slot C1: Red: On Memory Error(s)
LED_C2 Memory Fault Detect LED for memory slot C2: Red: On Memory Error(s)
LED_C3 Memory Fault Detect LED for memory slot C3: Red: On Memory Error(s)
LED_D1 Memory Fault Detect LED for memory slot D1: Red: On Memory Error(s)
LED_D2 Memory Fault Detect LED for memory slot D2: Red: On Memory Error(s)
LED_D3 Memory Fault Detect LED for memory slot D3: Red: On Memory Error(s)
LED_E1 Memory Fault Detect LED for memory slot E1: Red: On Memory Error(s)
LED_E2 Memory Fault Detect LED for memory slot E2: Red: On Memory Error(s)
LED_E3 Memory Fault Detect LED for memory slot E3: Red: On Memory Error(s)
LED_F1 Memory Fault Detect LED for memory slot F1: Red: On Memory Error(s)
LED_F2 Memory Fault Detect LED for memory slot F2: Red: On Memory Error(s)
LED_F3 Memory Fault Detect LED for memory slot F3: Red: On Memory Error(s)
LED_G1 Memory Fault Detect LED for memory slot G1: Red: On Memory Error(s)
LED_G2 Memory Fault Detect LED for memory slot G2: Red: On Memory Error(s)
LED_G3 Memory Fault Detect LED for memory slot G3: Red: On Memory Error(s)
LED_H1 Memory Fault Detect LED for memory slot H1: Red: On Memory Error(s)
LED_H2 Memory Fault Detect LED for memory slot H2: Red: On Memory Error(s)
LED_H3 Memory Fault Detect LED for memory slot H3: Red: On Memory Error(s)
Note: To turn off memory LEDs, please refer to "Turn off Memory Error
LEDS" in the Event Logs menu in Chapter 4. Refer to Chpt. 2 for more info.
