Chapter 1: Overview
1-7
Motherboard Features
CPU
Dual Intel
®
E5-2600v3 series processors (Socket R3-LGA
2011) w/dual full-width Intel QuickPath Interconnect (QPI)
links (9.6 GT/s max. one direction per QPI) support
Memory
Integrated memory controller supports DDR4 288-
pin memory of up to 1536 GB of Load Reduction
(LRDIMM) or up to 768 GB of Registered (RDIMM) EEC
2133/1866/1600 MHz modules in 24 DIMM slots.
Notes: 1. Memory speed support is depending
on the CPUs used in the motherboard. For the
latest CPU/memory updates, please refer to our
website at http://www.supermicro.com/products/
motherboard. Please also refer to the DDR4
Memory Configuration Guide at http://www.
supermicro.com/support/resources/memory/
X10_memory_cong_guide.pdf”
2. Please also refer to Page 1-6 for Memory
Fault LEDs.
DIMM sizes
DIMM Up to 64 GB @1.2V
Chipset
Intel® PCH C612
Three (3) PCI-Express 3.0 slots:
• SXB1A/1B/1C (WIO-Left): SMCI-proprietary PCI-E
slot for WIO riser card use (supported by CPU2)
• SXB3A/3B/3C SMCI-proprietary PCI-E slot for Ultra
riser card use (supported by CPU1) (Also, see the
note on "Network" below for information on additional
LAN support.)
• SXB2: SMCI-proprietary PCI-E 3.0x8 slot for WIO
riser cards (supported by CPU2)
Expansion
Slots
Graphics
Graphics Controller via ASpeed 2400 BMC
Network
ASpeed 2400 Base-board Controller (BMC) supports
IPMI_LAN 2.0
Note: For additional LAN connections, please
install an appropriate Ultra riser card on Slot
SXB3A/3B/3C. Also, refer to the AOC list
posted at http://www.supermicro.com/support/
resources/aoc/aoc_compatibility_ultra.cfm for
more info.
