2-14
X10DRU-i+ Motherboard User’s Manual
Memory Support for the X10DRU-i+ Motherboard
The X10DRU-i+ motherboard supports DDR4 288-pin memory of up to 1536 GB
of Load Reduction (LRDIMM) and up to 768 GB of Registered (RDIMM) EEC
2133/1866/1600 MHz modules in 24 DIMM slots.
Note1: Memory speed support is depending on the CPUs used in the
motherboard. For the latest CPU/memory updates, please refer to our
website at http://www.supermicro.com/products/motherboard. For more
information on DDR4 memory, please also refer to the DDR4 Memory
Conguration Guide at http://www.supermicro.com/support/resources/
memory/X10_memory_cong_guide.pdf”
Note 2: For information on the onboard Memory Fault LED indicators,
please refer to Page 1-6 and the LED section on Section 2-9 in Chapter 2.
Processor & Memory Module Population Conguration
For memory to work properly, follow the tables below for memory installation.
Processors and their Corresponding Memory Modules
CPU# Corresponding DIMM Modules
(CPU 1) P1-DIMM A1 B1 C1 D1 A2 B2 C2 D2 A3 B3 C3 D3
(CPU 2) P2-DIMM E1 F1 G1 H1 E2 F2 G2 H2 E3 F3 G3 H3
Populating RDIMM/LRDIMM DDR4 Memory Modules
INTEL CONFIDENTIAL
Intel and the Intel logo are trademarks or registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries. Other names and brands
may be claimed as the property of others. All products, dates, and figures are preliminary and are subject to change without any notice. Copyright © 2012, Intel Corporation.
1
An Important Note:
•For the memory modules to work properly, please install DIMM modules of the
same type, same speed and same operating frequency in the motherboard.
Mixing of DIMMs of different types or different speeds is not allowed.
