SuperServer E403-9P-FN2T User's Manual
Chassis Rear
The illustration below shows three system fans included on the rear of the chassis.
Figure 1-3. Rear View
System Fans
Figure 1-3. Rear I/O Ports
# Description # Description
1 COM Port 1 6 USB7 (3.0)
2 Dedicated BMC LAN 7 LAN1
3 USB1 (2.0) 8 LAN2
4 USB0 (2.0) 9 VGA Port
5 USB8 (3.0) 10 UID Switch
1
9
876
5
4
3
2
10
