Preparing the CPU Socket for Installation
This motherboard comes with a plastic protective cover on the CPU socket. Remove it
carefully to install the Processor Heatsink Module (PHM).
CPU Socket with Plastic Protective Cover
Socket Pins
Remove the plastic protective
cover from the CPU socket.
Do not touch or bend
the socket pins.
