9
Chapter 1: Introduction
1.3 System Features
The following table is an overview of the main features of the E403-9P-FN2T server.
System Features
Motherboard
X11SPW-TF
Chassis
E403iF
CPU
Single Intel Xeon 81xx/61xx/51xx/41xx/31xx or Xeon 82xx/62xx/52xx/42xx/32xx processors (Intel Scalable
Processors) in Socket P0 (LGA3647) For the latest CPU/memory updates, refer to our website at
http://www.supermicro.com/products/motherboard/Xeon/C620/X11SPW-TF.cfm.
Memory
Six slots for up to 1.5TB DDR4 3DS ECC RDIMM or LRDIMM memory with speeds of up to 2933MHz
Chipset
Intel C622
Expansion Slots
One PCIe 3.0 x16 slot and two PCIe 3.0 x8 slots, OR two PCIe 3.0 x16 slots
One M.2 M-Key 2280/22110 (PCIe 3.0 x4 / SATA3)
Storage Drives
(Optional) M.2: One PCIe M.2 M-Key
Power
600 W 80Plus Gold level module
Cooling
Input/Output
USB: four 3.0 ports; two USB 2.0 ports
One serial port; one VGA port
LAN ports
Two 10 GbE ports
One dedicated BMC port
Form Factor
Box; (WxHxD) 10.5 x 4.3 x 16 in. (267 x 109 x 406 mm)
