Chapter 2: Maintenance and Component Installation
3. Place the air shroud. The small rectangular portion covers the DIMMA1/DIMMB1/
DIMMC1 memory modules.
4. Replace the chassis cross bracket.
Checking the Server Air Flow
•
• Do not operate the server without drives or drive carriers in the drive bays.
• Use only recommended server parts.
•
The control panel LEDs display system heat status. See “Control Panel” in Chapter 1 for
details.
Overheating
There are several possible responses if the system overheats.
• Use the LEDs to determine the nature of the overheating condition.
•
• Make sure all fans are present and operating normally.
• Check the routing of the cables.
• Verify that the heatsinks are installed properly.
Expansion Cards
The system supports up to three PCIe cards on a riser card: One PCIe 3.0 x16 slot and two
Riser Card Jumper, JSEL1
Jumper
Setting
Slot1 Slot2 Slot3
1-2 x16 N/A x16
2-3 (default) x8 x8 x16
air shroud when using full height.
