Chapter 3: Motherboard Connections
Chapter 3
Motherboard Connections

             
The LEDs on the motherboard are also described here. A motherboard layout indicating
component locations may be found in Chapter 1.
Please review the Safety Precautions in Chapter 3 before installing or removing components.
3.1 Power Connections
Two power connections supply the motherboard and several more supply for onboard devices.
Main ATX Power Supply Connector

You must also connect the 8-pin (JPWR1) processor power connector to your power supply.
ATX Power 24-pin Connector
Pin Denitions
Pin# Denition Pin# Denition
13 +3.3V 1 +3.3V
14 -12V 2 +3.3V
15 GND 3 GND
16 PS_ON 4 +5V
17 GND 5 GND
18 GND 6 +5V
19 GND 7 GND
20 Res (NC) 8 PWR_OK
21 +5V 9 5VSB
22 +5V 10 +12V
23 +5V 11 +12V
24 GND 12 +3.3V
Secondary Power Connector
JPWR1 must also be connected to the power supply. This connector is used to power the
processor.
+12V 8-pin Power
Pin Denitions
Pin# Denition
1 - 4 GND
5 - 8 +12V
Required Connection
