SuperServer E403-9P-FN2T User's Manual
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the E403-9P-FN2T server.
It is based on the X11SPW-TF motherboard and the E403iF chassis.
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Main Parts List
Description Part Number Quantity
Power supply module PWS-601-1H 1
Add-on module for PCIe AOM-SDW-B16X2 1
Fans FAN-0200L4 3
Air Shroud MCP-310-40301-0B 1
Heatsink SNK-P0071VS 1
1.2 Unpacking the System
Inspect the box the system was shipped in and note if it was damaged in any way. If any
Decide on a suitable location for the server. It should be situated in a clean, dust-free area
are generated. It will also require a grounded AC power outlet nearby. Be sure to read the
precautions and considerations noted in Appendix B.
